Introduction

The field of electrochemical sensors in contemporary sensing systems has experienced numerous advancements stemming from the progress made in microelectronics and microengineering. These developments have primarily led to the creation of smaller sensors with heightened sensitivity and selectivity, while also reducing production and maintenance expenses. The ongoing research on electrochemical sensors focuses on investigating novel materials to enhance their selectivity capabilities as well as improve detection limits. The study of material behavior at the nanometric scale has contributed significantly to advancements in research and the practical use of electrochemical sensors and electroanalytical methods. The exploration of material behavior at the nanometric scale, which deals with dimensions and tolerances of less than 100 nanometers, has been pivotal in driving forward research and practical applications in the realm of electrochemical sensors and electroanalytical methods. At this minute scale, materials often exhibit unique physical and chemical properties that differ significantly from their bulk counterparts. These properties include increased reactivity, strength, electrical conductivity, and specific surface area. In the context of electrochemical sensors, such nanoscale materials provide enhanced sensitivity and selectivity for detecting various analytes. The increased surface area at the nanoscale allows for a higher density of reactive sites, thereby improving the sensor's responsiveness to target molecules. In addition, the nanoscale manipulation of materials has led to the development of more compact, efficient, and versatile sensors, which are crucial for real-time monitoring and analysis in environmental, medical, and industrial applications. These advancements in nanomaterials have also enabled the miniaturization of electroanalytical devices, making them more portable and user-friendly, thereby expanding their use beyond traditional laboratory settings into field applications and personal healthcare devices. This intersection of nanotechnology and electrochemical sensing is a testament to how studying materials at the nanometric scale can fundamentally transform and enhance technological capabilities.

Electrochemical sensors, which are a type of chemical sensor, have emerged as leaders in this field and have successfully transitioned into commercial applications. These sensors have proven to be invaluable tools in various areas such as clinical analysis, industrial processes, environmental monitoring, and agricultural studies [1,2,3,4,5,6,7].

The sensor is comprised of two primary components: a recognition element which facilitates selective and specific binding with the target analyte, and a transducer responsible for transmitting information regarding the binding. Parameters such as response time, signal-to-noise ratio (S/N), selectivity, linear range, and limit of detection (LoD) are all key factors in determining the effectiveness of these sensor components in recognizing and detecting analytes accurately. Enhancing the conductive properties of the sensor surface is a fundamental approach employed in the construction of electrochemical sensors to facilitate efficient electron transfer between the analyte surface and working electrode. Extensive research has been conducted on modifying the composition of the working electrode as a means to enhance both selectivity and sensitivity in electrochemical analysis. The working electrode plays a crucial role in amperometric and voltametric electrochemical sensors. Carbon-based electrodes, including carbon paste electrodes, glassy carbon electrodes, pencil graphite electrodes, screen printed electrodes, as well as metal-based gold electrodes, are commonly utilized and modified for this purpose [8,9,10,11,12,13].

Electrode surface modification can take the form of various techniques, including the application of an electroactive thin film, a single layer deposition method or a thicker layer created through strategies such as drop-casting [10,14,15,16,17]. Utilizing modified electrodes in voltametric analysis offers several advantages, including exceptionally low detection limits, enhanced selectivity and the capability to simultaneously determine multiple analytes [18,19,20,21]. Extensive research has been conducted on the advancement of electrochemical sensors for Cu(II) detection. This includes both conventional methods as well as contemporary approaches with and without modification [22,23,24,25,26,27].

Copper holds significant importance in various metabolic processes, making it an essential element for most organisms. Nevertheless, when present in high concentrations, copper can have detrimental effects on living organisms. Prolonged exposure to the elevated levels of copper in humans may lead to various adverse health issues including stomach discomfort, dizziness, vomiting, and diarrhea. In addition, excessive absorption of copper can result in liver and kidney damage as well as potentially fatal outcomes. As a result, there is a need for analytical methods with high sensitivity and low detection limits when determining the concentration of Cu(II) [28,29,30,31]. Two techniques commonly used for this purpose are coupled plasma emission spectrometry [32], and atomic emission spectroscopy [33]. However, these methods pose challenges due to their reliance on large instruments, costly maintenance requirements, and skilled operators.

In recent times, there has been a significant surge in research focused on ion-imprinted polymers for the detection of Cu ions [34,35]. This approach offers a straightforward design, excellent sensitivity, and a remarkable low detection limit [1,27] when it comes to determine Cu. Furthermore, the utilization of Cu(II) imprinted polymers  [36,37,38] in fabricating ion-selective electrodes highlights their distinctive features and wide range of applications in this field [25,26].

Ion-imprinted technology (IIT) emerged as a natural progression of molecular imprinting, sharing similar principles while focusing on ions as the templates. The synthesis of ion-imprinted polymers (IIP) typically involves various components such as template ions, functional monomers, crosslinkers, initiators, and solvents. In this context, the desired targets are usually specific ions that serve as templates for polymer formation. In the development and implementation process of IIP, various procedures are employed to combine template ions and functional monomers either through covalent or non-covalent bonding to create a pre-polymerization unit. Subsequently, polymers with significant cross-linking and rigidity are produced by utilizing initiators, cross-linking agents, as well as photoinitiated or thermally initiated polymerization techniques. In the end, the template ion is removed physically or chemically, resulting in a printed cavity that closely resembles both the size and structure of the template ion. These distinctive cavities exhibit high selectivity towards target ions through specific recognition mechanisms. To ensure the desired outcome of an IIP, careful consideration should be given to selecting the appropriate ion template, functional monomer, crosslinker, initiator, and solvent based on the target material [39,40,41].

While IIPs are known for their high selectivity, it is important to note that the incorporation of functional monomers and template ions within the polymer network can limit site accessibility for the target ion. Consequently, this may result in a reduced rate of mass transfer. To address this limitation, researchers have devised a method called surface ion-imprinted technology. This innovative approach utilizes supporting materials such as mesopore silica [42], MWCNT [43], and Fe₃O₄ [44] coated with a specialized polymer layer. This polymer layer possesses selectivity and effectively binds to the targeted metal ion through imprinting techniques.

The surface ion-imprinted polymer (SIIP) developed by SIIT has several advantages, including its high selectivity, increased accessibility to binding sites, elevated adsorption capacity, and rapid mass transfer rate [45]. By creating the recognition site on the support's surface instead of deep embedding it, SIIP exhibits improved accessibility to target ions while avoiding complications associated with deeper embedding techniques [46]. Generally, SIIT have been extensively employed for the separation of metal ions in various studies [47,48]. In our research endeavor, we have utilized SIIT to create a Cu (II) ion sensor through the implementation of voltammetry. This study aimed to develop an electrochemical sensor utilizing SIIT. The inclusion of Fe₃O₄ as a core material facilitates the separation process during synthesis [49,50,51].

The presence of hydroxyl groups on the surface of Fe₃O₄ poses challenges in grafting onto it. To overcome this issue, a silica coating is applied to enhance both the grafting ratio and anti-acid capacity of this composite material. The production of magnetic ion imprinted polymer (MIIP) involves the silica polymerization on Fe₃O₄ surfaces, leading to a stable product that retains its structural integrity even in acidic conditions [52.53].

This study involved the modification of a silica layer onto the surface of iron oxide (Fe₃O₄@SiO₂) using the sol-gel method. This process began with the preparation of a sol, a colloidal mixture of precursors such as tetraethyl orthosilicate (TEOS) with water, alcohol, and a catalyst like hydrochloric acid or ammonia. The sol underwent hydrolysis and polymerization reactions, leading to the formation of a gel-like network that coated the Fe3O4 particles. As the gel solidified, it created a porous, silica-rich layer on the Fe₃O₄ surface, enhancing its chemical and physical properties. Subsequently, the Cu(II)-APTES complex was grafted onto this modified surface of Fe₃O₄@SiO₂ particles, also known as magnetic ion-imprinted material (MIIM). This method leveraged the unique advantages of the sol-gel process, such as controlled porosity and surface area, to improve the material’s functionality in sensor applications. In recent studies, researchers have examined the application of Fe₃O₄ as a modifier in the working electrode to improve electrochemical sensors for detecting monosodium glutamate [54]. Furthermore, the inclusion of Fe₃O₄ in the nata de coco membrane has been found to enhance the potentiometric sensitivity of phenol sensors (Figure 1) [55,56,57].

The MIIM utilization as a modifier on the surface of screen-printed carbon electrodes (SPCE) offers a novel approach to enhance the sensitivity of electrochemical Cu sensors via voltammetry. This technique involves modifying SPCE with a molecularly imprinted polymer specifically designed for uric acid [58] and 4-aminophenol sensors, thereby improving their performance [59].

Chemicals

All reagents and chemicals utilized in this experiment were of analytical grade and were employed without any further purification. Carbon paste, Fe₃O₄, tetra ethyl ortho silicate (TEOS), 2-propanol, ammonia, copper sulfate, copper chloride, 3-aminopropyl tri ethoxy silane (APTES), methanol, and KCl were procured from Sigma-Aldrich in the United States. Sulfuric acid (H₂SO₄), hydrochloric acid, K₃Fe(CN)₆, K₄Fe(CN)₆, NaOH, KH₂PO₄, K₂HPO₄ from Merck; standard buffer at pH levels 4 and 7; as well as demineralized water was obtained for use.

Instrumentation

The Potentiostat/Galvanostat Autolab PGSTAT204 and DropSens µStat200 were utilized for the testing. Additional experimentation was conducted using a customized SPCE. The surface morphology of Fe₃O₄@SiO₂-IIM was assessed through SEM and FTIR analysis to evaluate the efficacy of synthesizing Fe₃O₄@SiO₂-IIM.

MIIM preparation

MIIM preparation refers to a procedure that has been developed by Luo et al. [22].

1. Fe₃O₄@SiO₂ Preparation

5 g Fe₃O₄ was added to 250 mL of 2-propanol and 2 mL of distilled water, sonicated for 15 min, and then added 20 mL ammonia and 33.3 mL TEOS, stirred for 12 h. Then, it is separated by a magnet. Then wash with distilled water until ammonia-free.

2. F Fe₃O₄@SiO₂-IIM or MIIM preparation.
3. 75 g CuCl₂ added 60 mL of methanol in a water bath and 4 mL of 3-aminopropyl tri ethoxy silane (APTES) stirred for 1 hour.
4. Fe₃O₄@SiO₂ of no. (1) is suspended into 50 mL of methanol, and then stirred and added to the mixture (a) above.
5. The mixture (a) and (b) is stirred for 24 hours at 40-50
6. Fe₃O₄@SiO₂ -IIM is separated with a magnet and washed with methanol and followed by HCl. 2 M and distilled water until HCl-free; check with litmus. Any Fe₃O₄@SiO₂ -IIM separation at the time of washing is magnetized.

SPCE modification

Three different combinations of mixtures can be used for modifying SPCE. These include a mixture containing equal amounts of carbon and MIIM in a 1:1 ratio, as well as a combination of 0.1 g each of MIIM and carbon, which is mixed with a few drops of paraffin oil and stirred to obtain a paste-like consistency. The paste was applied onto the surface of the working electrode on the SPCE, and subsequently dried at 50 °C for 10 minutes.

Electrochemical properties characterization

The electrochemical performance was evaluated through cyclic voltammetry on various sensor types including SPCE, SPCE-carbon paste, SPCE-MIIM, and SPCE-carbon paste-MIIM. To carry out the experiment, a 0.5 mM solution of [Fe(CN)₆]^3-/4- in KCl (0.01 M) was utilized as a standard solution. The potential was set at -1.0-1.0 Volt and the scan rate ranged from 50 to 200 mV with increments of 25 mV (i.e., 50,75,100,125,150). CV measurements were conducted on a 100 µM Cu solution in 0.01 M KCl, with a potential ranging from -0.5 to 0.5 Volt. The diffusion coefficient was determined by conducting measurements at scan rates of 50, 75, 100, 125,150, and 200 mV.

The Cu (II) sensor characterization

Effect of pH

The influence of the pH of the supporting electrolyte on the voltammetric response of SPCE, specifically SPCE-MIIM and SPCE-C-MIIM, was investigated in a pH range from 2.0 to 5.0 with a Cu concentration of 100 µM. The pH adjustment was achieved using Briton Robinson buffer solution. The measurements were conducted using CV (cyclic voltammetry) and SWV (square wave voltammetry).

The Cu(II) sensor performance

The evaluation of the proposed technique will involve an analysis of its linearity range and detection limit. The linearity range will be determined by observing the relationship between peak current and Cu(II) concentration, while the detection limit refers to the minimum value at which this relationship can be reliably detected. The concentration of Cu solutions was varied between 0.5-200 nM by dilution in a buffer solution at pH 3. SWV measurement with a frequency of 10 Hz and scan rate of 50 mV was conducted at a potential range of -0.5 to 0.2 Volt.

Results and Discussion

Characterization of magnetic ion imprinted material (Fe₃O₄@SiO₂-IIM)

The characterization of the magnetic ion imprinted material (Fe₃O₄@SiO₂-IIM) is demonstrated in Figure 2, where its FTIR spectrum is compared to that of commercial Fe₃O₄ utilized in this study. A noticeable distinction between the two spectra can be observed from the image.  The FTIR analysis of Fe₃O₄ reveals a single peak at a wave number of 533 cm^-1, suggesting the existence of Fe-O bonds [60,61].

On the other hand, in the FTIR spectrum of Fe₃O₄@SiO₂-IIM, distinct peaks can be observed: one at 1620 cm^-1 indicating the presence of a secondary amine group and others at 1043 cm^-1, 937 cm^-1 indicating siloxane groups such as Si-O-Si or Si-O-C and silica ions, respectively [62,63].

 The findings align with the SEM's EDX spectrum, suggesting that Fe, Si, O, and Cl are present in Fe₃O₄@SiO₂-IIM. The findings of the study, particularly in relation to the composition of the Fe3O4@SiO2-IIM (Iron Oxide at Silica-Ion Imprinted Material), show a strong correlation with the data obtained from the SEM's (Scanning Electron Microscopy) EDX (Energy-Dispersive X-ray) spectrum. The EDX spectrum, a technique used for elemental analysis or chemical characterization of a sample, revealed the presence of key elements: Iron (Fe), Silicon (Si), Oxygen (O), and Chlorine (Cl) in the synthesized material. Iron, being a primary component of Fe₃O₄, indicates the successful incorporation of iron oxide nanoparticles within the material's structure. Silicon and oxygen are indicative of the silica matrix, which is crucial for the stability and functionality of the ion-imprinted material. The presence of chlorine suggests the successful integration of chlorinated compounds or functional groups during the synthesis process, possibly from the precursors or catalysts used. This elemental composition confirms the successful formation of the Fe3O4@SiO2-IIM, with each element playing a critical role in the material’s properties and its subsequent application in electrochemical sensing. The alignment of these findings with the SEM's EDX spectrum not only validates the material's composition, but also underscores the effectiveness of using advanced microscopic and spectroscopic techniques for material characterization in nanotechnology and sensor development.

In addition, Figure 3b indicates the release of Cu(II).

Electrochemical characterization

The Fe(CN)₆^3-/4- 0.5 mM solution in 0.01 M KCl was subjected to CV measurements at different scan rates. The electrochemical reduction of ferricyanide ions to ferrocyanide and the subsequent oxidation process were performed on a SPCE electrode with a diameter of 3 mm, utilizing CV techniques at scan rates ranging from 50 mV s⁻¹ to 200 mV s^-1. Figure 4 displays the typical cyclic voltammetry response for redox couples, specifically for a solution containing 0.5 mM potassium ferricyanide

in a 0.01 M KCl solution. CV comprises of both an anodic sweep (forward sweep) and a cathodic sweep (reverse sweep). During the initial phase of the forward sweep, specifically before reaching 0.0 V, there is no occurrence of electrolysis.

However, once the voltage surpasses this threshold (0.0 V), an oxidation process initiates and gradually intensifies until it reaches its maximum value on the current-voltage curve. At this point, the graph showcases a distinct peak shape which suggests that the oxidation process becomes diffusion-limited. Following the continuation of the oxidation process, there is a decline in its rate. The overall outcome of this process involves the conversion of ferrocyanide into ferricyanide. The point at which the oxidation current reaches its highest magnitude is referred to as the anodic peak current (I_pa), while the maximum potential at that point is known as the anodic peak potential (E_pa).

The CV measurements yielded an E_pa value of 0.349 V and an I_pa value of 1.82×10⁻⁵ A. Interestingly, even in the reverse or cathodic sweep, the oxidation process still takes place followed by a subsequent reduction of [Fe(CN)₆]³⁻ that reaches its maximum point where the CV once again exhibits a peak shape. During the reduction process, the system eventually reaches its diffusion limit. At this point, the value of E_pc is measured to be 0.195 V and I_pc is found to be 3.22×10^-5 A. The reduction reaction then proceeds further. Analysis from a cyclic voltammetry experiment confirms that the redox reaction between ferricyanide and ferrocyanide involves the transfer of a single electron.  The experiment involved conducting measurements on various electrodes, specifically SPCE; SPCE-C-MIIM; SPCE-MIIM; and SPCE-C. Based on the data presented in Figure 5, a curve was formulated to establish a relationship between the square root of the scan rate (n) or ν^1/2 and the cathodic and anodic peak currents for predicting the diffusion coefficient of Fe(CN)₆^3-/4- for each sensor, as shown in Figure 5. According to Figure 4, analyzing the CV data and peak current values reveals that an increase in the scan rate leads to higher I_pa and I_pc peaks. This finding demonstrates a clear correlation between the peak current and scan rate, thereby confirming the relationship described in the Randles-Sevcik equation at 298.15 K.Where,    is the number of electrons involved in the redox half-reaction being studied,   is the diffusion coefficient for the redox active species,   is the molar concentration of the redox active species,   is the surface area of the electrode, and u is the rate at which the potential is being swept [63,64,65,66].

According to the findings presented in Figure 5, it is evident that the diffusion coefficient for Fe(CN)₆^3-/4- is highest when SPCE is modified with a combination of carbon paste-MIIM (SPCE-C-MIIM). As a result, this particular sensor exhibits the highest level of sensitivity. In consideration of the observed electrochemical properties of each sensor, it has been determined that the SPCE-C-MIIM sensor exhibits the highest sensitivity. Consequently, CV analysis was conducted on this particular sensor using a 100µM Cu(II) in a 0.01 M KCl solution.

Electrochemical analysis was also conducted on SPCE for the purpose of comparison, as demonstrated in Figure 6. The cyclic voltammogram of the Cu(II) solution in KCl revealed two distinct anodic peaks occurring at -0.14 and +0.2 Volts, indicating the presence of two oxidation states of Cu(II), that Cu(I) and Cu.

When utilizing Ag/AgCl as a reference electrode in 0.01 M KCl solution (E = 0.346 Volts), the reduction potentials mentioned above are altered to -0.193 and +0.175 Volts, correspondingly. The current height observed at the initial reduction level is significantly

higher than that of the second reduction (Figure 5). Hence, only the diffusion coefficient corresponding to the first reduction peak, which represents Cu(II) being reduced to Cu(I), is compared in the Cu(II) sensor. In terms of measurements, the application utilizes SWV technique and focuses on observing the first reduction peak.  As illustrated in Figure 7b, it is evident that SPCE-C-MIIM's Cu(II) sensor exhibits the highest diffusion coefficient among other sensors tested. The addition of carbon paste enhances electron delivery conductivity due to the conductive nature of carbon (»103 S/m) [67,68]. Consequently, the Cu(II) sensor can be labeled as SPCE-C-MIIP based on its diffusion coefficient.

Effect of pH

Understanding the impact of pH is crucial in investigating how the solubility of Cu(II) in water can be influenced. It has been observed that under acidic conditions, specifically at a pH range between 1 to 2, Cu(II) ions exhibit high solubility. At a slightly higher pH value of 3, the Cu(I) formation starts to occur and it still remains soluble in water. However, starting from a pH level of 6 onwards, the formation of Cu(II) takes place and its solubility decreases considerably (K_sp = 4.8 x 10^-20) [69,70].

In this particular study, observations were made within a range of pH values ranging from 2 to 5 using Britton Robinson buffer as an electrolyte support. The pH influence on the peak current of the SWV voltammogram can be observed in Figure 8. To compare the effects, both sensors (Cu(II) from SPCE-C-MIIM and Cu(II) from SPCE-MIIM) were studied alongside an SPCE as a control since their diffusion coefficients are similar. The linear regression equations presented in Table 1 were essential in this analysis, offering a quantitative framework to compare the performance of various Cu(II) sensors under different pH conditions.

The peak current (I_p) of the SWV voltammogram in SPCE is higher than in modified SPCE, but the data has a large deviation from 5 repetitions. At pH 2 the I_p of the modified SPCE is lower than the I_p at pH 3, and tends to decrease at pH 4 and 5. This may be caused by the charge of the Cu ion. At pH 2, the Cu ion in solution is dominated by Cu²⁺, while at pH 3, it is dominated by Cu(OH)⁺. It is estimated that the diffusion speed of Cu(OH)⁺ is higher than Cu²⁺, so that Ip is higher at pH 3. This does not happen at unmodified SPCE, because its surface is not selective . At pH 4 and 5 Cu(OH)₂ begins to form, so that the Cu(OH)⁺  begins to decrease, as a result I_p decreases. The effect of pH in SPCE-MIIM and SPCE-C-MIIM, on I_p, has almost the same profile, but the deviation in SPCE-MIIM is higher.

The Cu(II) sensor performance

The detection of Cu(II) ions by square wave voltammetry method was performed on three different platforms: unmodified SPCE, SPCE modified by MIIP/Cu (referred to as SPCE-MIIP), and a paste made from carbon and MIIP/Cu (known as SPCE-C-MIIP). Figure 9 presents the SWV peak current obtained at various concentrations of Cu(II) at pH 3 in Britton Robinson buffer solution. The measurements were conducted using CV (cyclic voltammetry) and SWV (square wave voltammetry).

To evaluate the performance of the SPCE-C-MIIP sensor, a retest was conducted using various concentrations of Cu(II) ranging from 0 to 200 nM. by SWV method, the voltammogram shown in Figure 10a. From the voltammogram in Figure 10a, a standard curve was created, resulting a regression equation I_p = 0.49 C with a sensitivity of 0.49 µA/nM and a LoD is 3 nM. Sensor accuracy was determined by standard addition for three surface water samples. Each sample was added by 20 nM Cu(II), the voltammogram can be seen in Figure 10b. The sample’s acidity was adjusted to pH 3 by Britton Robinson buffer in SWV analysis. The average accuracy of the standard addition results for the three water samples was (102.7±1.5)%.

Conclusion

To sum up, this study has successfully developed a novel electrochemical sensor that significantly enhances the detection of Cu(II) ions. The key innovation lies in the use of the Fe₃O₄@SiO₂-(Cu(II))-APTES composite (MIIM) and its integration with a screen-printed carbon electrode (SPCE). This combination, particularly when augmented with carbon paste, has led to remarkable improvements in sensitivity and accuracy over traditional SPCE sensors. The standout performer, the SPCE-C-MIIM sensor, showcases exceptional electrochemical properties, achieving high sensitivity, a remarkably low detection limit, and impressive accuracy under specific conditions. The significant advancements in detecting Cu(II) ions with these sensors, especially their potential application in analyzing surface water samples, mark a substantial step forward in environmental monitoring and public health protection. This breakthrough underscores the transformative impact of innovative material design and composite integration in enhancing the capabilities of electrochemical sensors.

Acknowledgments

The authors express gratitude to the Institute for Research and Community Service at Brawijaya University for providing financial support for this study through the PTNBH 2023 Collaboration Grant scheme. Grant of Program Penelitian Kolaborasi Indonesia-21 PTNBH for 2023 with contract number: 801.11/UN10.C10/TU/2023.
